D Subminiature
C ommercial Micro D — MDSM
Locking/Latching Options
Jackscrew
Push/Pull
The jackscrew locking system is designed for applications which require a The push/pull latching system is designed for applications which require a
secureconnection. Utilizethumbscrews whentheconnectors areinfrequently quickconnectanddisconnect. Aspringretentionmechanismlatches toapost
unmated.
on the board side to prevent unintentional unmatings.
Z10 Jackpost
Z42 Jackpost
0,52 (.020)
#2-56 UNC
#2-56 UNC
¯
3,25
3,18 (.125)
HE X
(AC R OS S FLATS )
(.128)
6,45
(.254)
6,45
(.254)
1,25 (.049)
1,25 (.049)
Note: Two Jackposts supplied with boardside connectors.
Note: Two Jackposts supplied with boardside connectors.
Dimensions are shown in mm(inch)
Dimensions subject to change
