D Subminiature
Combo D
PCB Guide Pin and Socket
Installs into any Combo D, Size 8 cavity. This guide
pin and socket system is ideal for blind mate
applications where space is limited.
PCB Guide Pin
29,21 (1.150)
REF
3,68 - 3,43
(.145 - .135)
11,43 (.450)
REF
Ø 5,66 - 5,41
(.223 - .213)
Part Number
Material
Finish
DM53745-126
Copper Alloy
Tin
Ø 3,25 - 3,10
(.128 - .122)
RING, RETAINING
PCB Guide Socket
4,06 (.160)
CONNECTOR REAR
INSULATOR REF
Part Number
Material
Finish
16,28 (.641)
REF
248-2967-000
Copper Alloy
Tin
Dimensions are shown in mm (inch)
Dimensions subject to change
