D Subminiature
Commercial Micro D — MDSM
MDSM SSA Compatible Cable Assemblies
ITT Cannon’s 9 position MDSM connectors have interfaces. SSA permits the transfer of data at
been designed into the ANSI specification called progressively higher speeds - 20 MB/sec interface
SSA, ‘‘Serial Storage Architecture,’’ as the external currently available with 40 MB/sec becoming
I/O. SSA is a new s erial interface for available in 1997/98. ITT Cannon’s MDSM
interconnecting storage devices, storage connector not only functions at these high speeds,
subsystems, servers and workstations. Storage but also brings to SSA smaller, less cumbersome
subsystems are increasing in function, availability, and higher reliability cables and connectors than
density and performance. With this comes the current options.
trend for them to become more complex and
ITT Cannon has the interconnect system which ITT Cannon is offering SSA compatable external
meets SSA’s high performance requirements.
cable assemblies in six different lengths to meet
your needs. These assemblies consist of two
SSA is an architecture which allows these new MDSM 9SC type cable connectors terminated to
subsystems to be implemented more easily and at SSA specified external cable.
lower costs than other new high speed parallel
X
5,71 (.225)
19,89
(.783)
MAX
14,35
(.565)
41,62
(1.639)
MAX
56,01
(2.205)
REF
Note: Cables shown with Z50 thumbscrews.
X
Part Number
CA112104
Meter (Feet)
0,50 (1.600)
1,00 (2.200)
3,00 (9.800)
5,00 (16.400)
10,00 (32.800)
20,00 (65.600)
Tolerance
25,00 (1.000)
25,00 (1.000)
25,00 (1.000)
64,00 (2.500)
64,00 (2.500)
64,00 (2.500)
CA112104-1
CA112104-2
CA112104-3
CA112104-4
CA112104-5
Note: For push/pull assemblies or other thumbscrews, please consult the factory.
Crimp dies for SSA applications will be offered by ITT Cannon. Consult factory for details.
Dimensions are shown in mm (inch)
Dimensions subject to change
102
