The Special Mask Mode is set by OCW3 where: ESMM = 1, The word enabled onto the data bus during RD is:
SMM = 1, and cleared where ESMM = 1, SMM = 0.
D7
D6
D5
D4
D3
D2
D1
D0
Poll Command
I
-
-
-
-
W2
W1
W0
In this mode, the INT output is not used or the microproces-
sor internal Interrupt Enable flip flop is reset, disabling its
interrupt input. Service to devices is achieved by software
using a Poll command.
W0 - W2: Binary code of the highest priority level request-
ing service.
I:
Equal to a “1” if there is an interrupt.
The Poll command is issued by setting P = 1 in OCW3. The
82C59A treats the next RD pulse to the 82C59A (i.e., RD =
0, CS = 0) as an interrupt acknowledge, sets the appropriate
IS bit if there is a request, and reads the priority level. Inter-
rupt is frozen from WR to RD.
This mode is useful if there is a routine command common to
several levels so that the INTA sequence is not needed (saves
ROM space). Another application is to use the poll mode to
expand the number of priority levels to more than 64.
LTIM BIT
0 = EDGE
1 = LEVEL
TO OTHER PRIORITY CELLS
CLR ISR
CLR
EDGE
SENSE
LATCH
Q
ISR BIT
PRIORITY
RESOLVER
SET
CLR
Q
SET ISR
V
CC
IN - SERVICE
LATCH
SET
CONTROL
LOGIC
REQUEST
LATCH
D
C
Q
Q
NON-
MASKED
REQ
IR
MASK LATCH
D
C
Q
INTA
8080/85
MODE
CLR
FREEZE
INTA
READ IMR
80C86/
88/286
MODE
READ ISR
FREEZE
READ WRITE
IRR MASK
MASTER CLEAR
FREEZE
NOTES:
1. Master clear active only during ICW1.
2. FREEZE is active during INTA and poll sequence only.
3. Truth Table for D-latch.
C
1
0
D
D1
X
Q
Operation
Follow
Hold
D1
Qn-1
FIGURE 9. PRIORITY CELL - SIMPLIFIED LOGIC DIAGRAM
Reading the 82C59A Status
The input status of several internal registers can be read to Interrupt Mask Register: 8-bit register which contains the
update the user information on the system. The following interrupt request lines which are masked.
registers can be read via OCW3 (lRR and ISR) or OCW1
The lRR can be read when, prior to the RD pulse, a Read
(lMR).
Register Command is issued with OCW3 (RR = 1, RIS = 0).
Interrupt Request Register (IRR): 8-bit register which con-
The ISR can be read when, prior to the RD pulse, a Read
tains the levels requesting an interrupt to be acknowledged.
Register Command is issued with OCW3 (RR = 1, RIS = 1).
The highest request level is reset from the lRR when an
interrupt is acknowledged. lRR is not affected by lMR.
There is no need to write an OCW3 before every status read
operation, as long as the status read corresponds with the
previous one: i.e., the 82C59A “remembers” whether the lRR
or ISR has been previously selected by the OCW3. This is
not true when poll is used. In the poll mode, the 82C59A
In-Service Register (ISR): 8-bit register which contains the
priority levels that are being serviced. The ISR is updated
when an End of Interrupt Command is issued.
4-12
