Chapter 5. DC & Switching
Characteristics
MII51005-1.7
Tables 5–1 through 5–12 provide information on absolute maximum
ratings, recommended operating conditions, DC electrical characteristics,
and other specifications for MAX® II devices.
Operating
Conditions
Absolute Maximum Ratings
Table 5–1 shows the absolute maximum ratings for the MAX II device
family.
Table 5–1. MAX II Device Absolute Maximum Ratings
Notes (1), (2)
Symbol
Parameter
Conditions
Minimum
–0.5
Maximum
4.6
Unit
V
VCCINT
With respect to ground
Internal Supply voltage (3)
I/O Supply Voltage
VCCIO
VI
–0.5
4.6
V
DC input voltage
–0.5
4.6
V
IOUT
TSTG
TAMB
TJ
DC output current, per pin
Storage temperature
Ambient temperature
Junction temperature
–25
25
mA
° C
° C
° C
No bias
–65
150
Under bias
–65
135
TQFP and BGA packages
under bias
135
Notes to Table 5–1:
(1) See the Operating Requirements for Altera Devices Data Sheet.
(2) Conditions beyond those listed in Table 5–1 may cause permanent damage to a device. Additionally, device
operation at the absolute maximum ratings for extended periods of time may have adverse affects on the device.
(3) Maximum VCCINT for MAX II devices is 4.6 V. For MAX IIG devices, it is 2.4 V.
