Host-PCI Express* Bridge Registers (D1:F0)
(Intel® 82915G/82915P/82915PL Only)
R
8.1.29
MA—Message Address (D1:F0)
PCI Device:
Address Offset:
Default Value:
Access:
1
94h
00000000h
RO, R/W
32 bits
Size:
Bit
Access &
Default
Description
31:2
R/W
Message Address: This field is used by system software to assign an MSI
00000000 h
address to the device.
The device handles an MSI by writing the padded contents of the MD register to
this address.
1:0
RO
Force DWord Align: Hardwired to 0 so that addresses assigned by system
00b
software are always aligned on a DWord address boundary.
8.1.30
MD—Message Data (D1:F0)
PCI Device:
Address Offset:
Default Value:
Access:
1
98h
0000h
R/W
16 bits
Size:
Bit
Access &
Default
Description
15:0
R/W
Message Data: This field provides a base message data pattern assigned by
0000h
system software and used to handle an MSI from the device.
When the device must generate an interrupt request, it writes a 32-bit value to
the memory address specified in the MA register. The upper 16 bits are always
set to 0. This register supplies the lower 16 bits.
Datasheet
149
