Host-PCI Express* Bridge Registers (D1:F0)
(Intel® 82915G/82915P/82915PL Only)
R
8.1.35
DSTS—Device Status (D1:F0)
PCI Device:
Address Offset:
Default Value:
Access:
1
AAh
0000h
RO
Size:
16 bits
This register reflects status corresponding to controls in the Device Control register.
Note: The error reporting bits are in reference to errors detected by this device, not errors messages
received across the link.
Bit
Access &
Default
Description
15:6
5
Reserved
RO
0b
Transactions Pending
0 = All pending transactions (including completions for any outstanding non-
posted requests on any used virtual channel) have been completed.
1 = Device has transaction(s) pending (including completions for any outstanding
non-posted requests for all used Traffic Classes).
4
3
Reserved
R/WC
0b
Unsupported Request Detected:
1 = Device received an Unsupported Request. Errors are logged in this register
regardless of whether error reporting is enabled or not in the Device Control
Register.
2
1
0
R/WC
0b
Fatal Error Detected:
1 = Fatal error(s) were detected. Errors are logged in this register regardless of
whether error reporting is enabled or not in the Device Control register.
R/WC
0b
Non-Fatal Error Detected:
1 = Non-fatal error(s) were detected. Errors are logged in this register regardless
of whether error reporting is enabled or not in the Device Control register.
R/WC
0b
Correctable Error Detected:
1 = Correctable error(s) were detected. Errors are logged in this register
regardless of whether error reporting is enabled or not in the Device Control
register.
Note: The (G)MCH may report a false 8B/10B Receiver Error when exiting L0s.
This is reported thru the Correctable Error Detected bit CESTS device 1, offset
1D0h, Bit [0]. This will reduce the value of Receiver Error detection when L0s is
enabled. Disable L0s for accurate Receiver Error reporting.
Datasheet
153
