MOBILE PENTIUM PROCESSOR WITH MMX™ TECHNOLOGY
Table 11. DC Specifications1
Symbol
Parameter
Input Low Voltage
Input High Voltage
Output Low Voltage
Output High Voltage
Min
-0.3
Max
0.5
Unit
V
Notes
VIL3
VIH3
VCC3 - 0.7
VCC3 + 0.3
0.4
V
TTL Level
VOL3
VOH3
V
TTL Level1
TTL Level2
TTL Level3
V CC3 - 0.4
V CC3 - 0.2
V
V
NOTES:
1. Parameter measured at -4 mA..
2. Parameter measured at 3 mA.
3. Parameter measured at 1mA; not 100% tested, guaranteed by design.
Table 12. ICC Specifications
Min Max
Symbol
Parameter
Unit
Notes
ICC2
Power Supply Current
2.35
2.70
3.10
4.00
A
A
A
A
166 MHz1
200 MHz1
233 MHz1
266 MHz1
ICC3
Power Supply Current
0.33
0.33
0.38
0.38
A
A
A
A
166 MHz1
200 MHz1
233 MHz1
266 MHz1
NOTE:
1. This value should be used for power supply design. It was determined using a worst case instruction mix and maximum
VCC at Tcase = 0C. Power supply transient response and decoupling capacitors must be sufficient to handle the
instantaneous current changes occurring during transitions from Stop Clock to full Active modes.
