Electrical Specifications
3
Electrical Specifications
3.1
Power and Ground Pins
For clean, on-chip power distribution, the Celeron M processor has a large number of
VCC (power) and VSS (ground) inputs. All power pins must be connected to VCC power
planes while all VSS pins must be connected to system ground planes. Use of multiple
power and ground planes is recommended to reduce I*R drop. Please refer to the
platform design guides for more details. The processor VCC pins must be supplied the
voltage determined by the VID (Voltage ID) pins.
3.1.1
FSB Clock (BCLK[1:0]) and Processor Clocking
BCLK[1:0] directly controls the FSB interface speed as well as the core frequency of the
processor. As in previous generation processors, the Celeron M processor core
frequency is a multiple of the BCLK[1:0] frequency. The Celeron M processor uses a
differential clocking implementation.
3.2
Voltage Identification and Power Sequencing
The Celeron M processor uses six voltage identification pins, VID[5:0], to support
automatic selection of power supply voltages. The VID pins for Celeron M processor are
CMOS outputs driven by the processor VID circuitry. Table 1 specifies the voltage level
corresponding to the state of VID[5:0].
