Processor Configuration Registers
2.21.2
CAP_REG—Capability Register
This register reports general remapping hardware capabilities.
B/D/F/Type:
Address Offset:
Reset Value:
Access:
0/0/0/VC0PREMAP
8–Fh
00C9008020660262h
RO
64 bits
000h
Size:
BIOS Optimal Default
Reset
Value
RST/
PWR
Bit
Access
Description
63:56
RO
0h
Reserved (RSVD)
DMA Read Draining (DRD)
55
54
RO
RO
1b
Uncore
Uncore
0 = Hardware does not support draining of DMA read requests.
1 = Hardware supports draining of DMA read requests.
DMA Write Draining (DWD)
0 = Hardware does not support draining of DMA write requests.
1 = Hardware supports draining of DMA write requests.
1b
Maximum Address Mask Value (MAMV)
The value in this field indicates the maximum supported value for
the Address Mask (AM) field in the Invalidation Address register
(IVA_REG) and IOTLB Invalidation Descriptor (iotlb_inv_dsc).
This field is valid only when the PSI field in Capability register is
reported as set.
53:48
47:40
RO
RO
001001b
Uncore
Uncore
Number of Fault-recording Registers (NFR)
The number of fault recording registers is computed as N+1,
where N is the value reported in this field.
Implementations must support at least one fault recording
register (NFR = 0) for each remapping hardware unit in the
platform.
00000000
b
The maximum number of fault recording registers per remapping
hardware unit is 256.
Page Selective Invalidation (PSI)
0 = Hardware supports only domain and global invalidates for
IOTLB
1 = Hardware supports page selective, domain and global
invalidates for IOTLB.
Hardware implementations reporting this field as set are
recommended to support a Maximum Address Mask Value
(MAMV) value of at least 9.
39
RO
RO
1b
0h
Uncore
38:38
Reserved (RSVD)
Super-Page Support (SPS)
This field indicates the super page sizes supported by hardware.
A value of 1 in any of these bits indicates the corresponding
super-page size is supported. The super-page sizes
corresponding to various bit positions within this field are:
0 = 21-bit offset to page frame (2 MB)
1 = 30-bit offset to page frame (1 GB)
2 = 39-bit offset to page frame (512 GB)
3 = 48-bit offset to page frame (1 TB)
37:34
RO
0000b
Uncore
Hardware implementations supporting a specific super-page size
must support all smaller super-page sizes; that is, only valid
values for this field are 0001b, 0011b, 0111b, 1111b.
