Electrical Specifications
10.The specification is defined per PLL pin.
11.The voltage response to a processor current load step (transient) must stay within the Transient Voltage
Tolerance Window. The voltage surge or droop response measured in this window is typically on the order of
several hundred nanoseconds to several microseconds. The Transient Voltage Tolerance Window is defined
as follows:
Case a) Load Current Step Up: e.g., from Icc = I_leakage to Icc = Icc_max. Allowable Vcc_min is defined as
minimum transient voltage at Icc = Icc_max for a period of time lasting several hundred nanoseconds to
several microseconds after the transient event.
Case b) Load Current Step Down: e.g., form Icc = Icc_max to Icc = I_leakage. Allowable Vcc_max is defined
as the maximum transient voltage at Icc = I_leakage for a period of time lasting several hundred
nanoseconds to several microseconds after the transient event.
12.This specification applies to both static and transient components. The rising edge of VCCVID must be
monotonic from 0 to 1.1 V. See Figure 1 for current requirements. In this case, monotonic is defined as
continuously increasing with less than 50 mV of peak to peak noise for any width greater than 2 nS
superimposed on the rising edge.
Table 8. IMVP-III Voltage Regulator Tolerances for VID = 1.30 V Operating Mode (Maximum
Performance Mode)
VCC Nominal
(V)
VCC Static Min VCC Static Max
VCC Transient
Min (V)
VCC Transient
Max (V)
ICC (A)
(V)
(V)
0.0
1.0
1.300
1.298
1.296
1.294
1.292
1.290
1.288
1.286
1.284
1.282
1.280
1.278
1.276
1.274
1.272
1.270
1.268
1.266
1.264
1.262
1.260
1.258
1.256
1.254
1.252
1.275
1.273
1.271
1.269
1.267
1.265
1.263
1.261
1.259
1.257
1.255
1.253
1.251
1.249
1.247
1.245
1.243
1.241
1.239
1.237
1.235
1.233
1.231
1.229
1.227
1.325
1.323
1.321
1.319
1.317
1.315
1.313
1.311
1.309
1.307
1.305
1.303
1.301
1.299
1.297
1.295
1.293
1.291
1.289
1.287
1.285
1.283
1.281
1.279
1.277
1.255
1.253
1.251
1.249
1.247
1.245
1.243
1.241
1.239
1.237
1.235
1.233
1.231
1.229
1.227
1.225
1.223
1.221
1.219
1.217
1.215
1.213
1.211
1.209
1.207
1.345
1.343
1.341
1.339
1.337
1.335
1.333
1.331
1.329
1.327
1.325
1.323
1.321
1.319
1.317
1.315
1.313
1.311
1.309
1.307
1.305
1.303
1.301
1.299
1.297
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
14.0
15.0
16.0
17.0
18.0
19.0
20.0
21.0
22.0
23.0
24.0
