Electrical Specifications
Table 8. IMVP-III Voltage Regulator Tolerances for VID = 1.30 V Operating Mode (Maximum
Performance Mode)
VCC Nominal
(V)
VCC Static Min VCC Static Max
VCC Transient
Min (V)
VCC Transient
Max (V)
ICC (A)
(V)
(V)
25.0
26.0
27.0
28.0
29.0
30.0
31.0
32.0
33.0
34.0
35.0
36.0
37.0
38.0
39.0
40.0
1.250
1.248
1.246
1.244
1.242
1.240
1.238
1.236
1.234
1.232
1.230
1.228
1.226
1.224
1.222
1.220
1.225
1.223
1.221
1.219
1.217
1.215
1.213
1.211
1.209
1.207
1.205
1.203
1.201
1.199
1.197
1.195
1.275
1.273
1.271
1.269
1.267
1.265
1.263
1.261
1.259
1.257
1.255
1.253
1.251
1.249
1.247
1.245
1.205
1.203
1.201
1.199
1.197
1.195
1.193
1.191
1.189
1.187
1.185
1.183
1.181
1.179
1.177
1.175
1.295
1.293
1.291
1.289
1.287
1.285
1.283
1.281
1.279
1.277
1.275
1.273
1.271
1.269
1.267
1.265
Figure 4. Illustration of V Static and Transient Tolerances (VID = 1.30 V)
CC
Mobile Northwood Load Line for VID = 1.30V
1.400
Vcc Transient Maximum
1.350
Vcc Static Maximum
Vcc Nominal
1.300
1.250
1.200
Vcc Static Minimum
1.150
Vcc Transient
1.100
1.050
Icc Maximum
26
