Electrical Specifications
2.10
Maximum Ratings
Table 6 lists the processor’s maximum environmental stress ratings. The processor should not
receive a clock while subjected to these conditions. Functional operating parameters are listed in
the AC and DC tables. Extended exposure to the maximum ratings may affect device reliability.
Furthermore, although the processor contains protective circuitry to resist damage from Electro
Static Discharge (ESD), one should always take precautions to avoid high static voltages or electric
fields.
Table 6. Processor DC Absolute Maximum Ratings
Symbol
Parameter
Min
Max
Unit
Notes
Processor storage
temperature
TSTORAGE
–40
85
°C
2
Any processor supply
voltage with respect to VSS
VCC
-0.3
-0.1
1.75
1.75
V
V
1
AGTL+ buffer DC input
voltage with respect to VSS
VinAGTL+
Asynch GTL+ buffer DC
VinAsynch_GTL+ input voltage with respect
to VSS
-0.1
1.75
5
V
IVID
Max VID pin current
mA
NOTES:
1. This rating applies to any processor pin.
2. Contact Intel for storage requirements in excess of one year.
2.11
Processor DC Specifications
The processor DC specifications in this section are defined at the processor core (pads) unless
noted otherwise. See Section 5 for the pin signal definitions and signal pin assignments. Most of
the signals on the processor system bus are in the AGTL+ signal group. The DC specifications for
these signals are listed in Table 13.
Previously, legacy signals and Test Access Port (TAP) signals to the processor used low-voltage
CMOS buffer types. However, these interfaces now follow DC specifications similar to GTL+. The
DC specifications for these signal groups are listed in Table 14 and Table 15.
Table 7 through Table 17 list the DC specifications for the Mobile Intel Pentium 4 Processor-M and
are valid only while meeting specifications for junction temperature, clock frequency, and input
voltages. Unless specified otherwise, all specifications for the Mobile Intel Pentium 4 Processor-M
are at T = 100°C. Care should be taken to read all notes associated with each parameter.
J
Mobile Intel Pentium 4 Processor-M Datasheet
23
