XMC4500
XMC4000 Family
Electrical Parameters
3.2.6
USB OTG Interface DC Characteristics
The Universal Serial Bus (USB) Interface is compliant to the USB Rev. 2.0 Specification
and the OTG Specification Rev. 1.3. High-Speed Mode is not supported.
Note: These parameters are not subject to production test, but verified by design and/or
characterization.
Table 26
USB OTG VBUS and ID Parameters (Operating Conditions apply)
Parameter
Symbol
Values
Unit Note /
Test Condition
Min.
VIN CC 0.0
Typ. Max.
VBUS input voltage
range
−
−
−
−
−
−
−
−
−
−
5.25
V
A-device VBUS valid VB1 CC 4.4
threshold
−
V
A-device session valid VB2 CC 0.8
threshold
2.0
4.0
0.8
100
−
V
B-device session valid VB3 CC 0.8
threshold
V
B-device session end VB4 CC 0.2
threshold
V
VBUS input
resistance to ground CC
RVBUS_IN 40
kOhm
B-device VBUS pull- RVBUS_PU 281
up resistor
Ohm Pull-up voltage =
3.0 V
CC
B-device VBUS pull- RVBUS_PD 656
down resistor
−
Ohm
CC
USB.ID pull-up
resistor
RUID_PU
CC
14
25
150
kOhm
VBUS input current
IVBUS_IN
−
μA
0 V ≤ VIN ≤ 5.25 V:
CC
TAVG = 1 ms
Data Sheet
52
V1.0, 2013-01
