XMC4500
XMC4000 Family
Electrical Parameters
Table 27
USB OTG Data Line (USB_DP, USB_DN) Parameters (Operating
Conditions apply)
Parameter
Symbol
Values
Unit
Note /
Test Condition
Min.
Typ. Max.
Input low voltage
VIL SR −
−
−
0.8
V
V
Input high voltage
(driven)
VIH SR 2.0
−
Input high voltage
(floating) 1)
VIHZ SR 2.7
VDIS CC 0.2
VCM CC 0.8
VOL CC 0.0
VOH CC 2.8
−
−
−
−
−
−
−
3.6
V
Differential input
sensitivity
−
V
Differential common
mode range
2.5
V
Output low voltage
0.3
V
1.5 kOhm pull-
up to 3.6 V
Output high voltage
3.6
V
15 kOhm pull-
down to 0 V
DP pull-up resistor (idle RPUI CC 900
bus)
1 575
3 090
Ohm
Ohm
DN pull-up resistor
(upstream port
receiving)
RPUA CC 1 425
DP, DN pull-down
resistor
RPD CC 14.25
ZINP CC 300
−
−
−
24.8
−
kOhm
Input impedance DP,
DN
kOhm 0 V ≤ VIN ≤ VDDP
Driver output resistance ZDRV CC 28
44
Ohm
DP, DN
1) Measured at A-connector with 1.5 kOhm ± 5% to 3.3 V ± 0.3 V connected to USB_DP or USB_DN and at B-
connector with 15 kOhm ± 5% to ground connected to USB_DP and USB_DN.
Data Sheet
53
V1.0, 2013-01
