XMC4500
XMC4000 Family
Electrical Parameters
3.2.4
Out-of-Range Comparator (ORC)
The Out-of-Range Comparator (ORC) triggers on analog input voltages (VAIN) above the
analog reference1) (VAREF) on selected input pins (GxORCy) and generates a service
request trigger (GxORCOUTy).
Note: These parameters are not subject to production test, but verified by design and/or
characterization.
The parameters in Table 24 apply for the maximum reference voltage
V
AREF = VDDA + 50 mV.
Table 24
ORC Parameters (Operating Conditions apply)
Parameter
Symbol
Values
Unit Note / Test Condition
Min.
DC Switching Level VODC CC 100
Hysteresis VOHYS CC 50
Typ. Max.
125
−
200
mV VAIN ≥ VAREF + VODC
VODC mV
Detection Delay of a tODD CC 55
−
450
105
ns
ns
VAIN ≥ VAREF + 200 mV
VAIN ≥ VAREF + 400 mV
persistent
45
−
Overvoltage
Always detected
Overvoltage Pulse
tOPDD CC 440
−
−
ns
ns
ns
ns
ns
ns
VAIN ≥ VAREF + 200 mV
VAIN ≥ VAREF + 400 mV
VAIN ≥ VAREF + 200 mV
VAIN ≥ VAREF + 400 mV
VAIN ≤ VAREF
90
−
−
Never detected
Overvoltage Pulse
tOPDN CC
−
−
−
49
30
105
200
−
Release Delay
Enable Delay
tORD CC 65
tOED CC −
−
100
1) Always the standard VADC reference, alternate references do not apply to the ORC.
