XMC4500
XMC4000 Family
Electrical Parameters
Table 20
Standard_Pads Class_A2
Parameter
Symbol
Min.
Values
Max.
Unit Note /
Test Condition
Input Leakage current IOZA2
-6
6
μA
μA
0 V ≤ Vi <
CC
0.5*VDDP - 1 V;
0.5*VDDP + 1 V
<Vi ≤ VDDP
-3
3
0.5*VDDP - 1 V <
Vi < 0.5*VDDP
+ 1 V
Input high voltage
Input low voltage
VIHA2
SR
0.6 × VDDP
V
DDP + 0.3 V
max. 3.6 V
V
ILA2 SR -0.3
0.36 ×
V
VDDP
Output high voltage,
POD = weak
VOHA2
CC
V
DDP - 0.4
−
V
V
V
V
V
V
V
IOH ≥ -400 μA
IOH ≥ -500 μA
IOH ≥ -1.4 mA
IOH ≥ -2 mA
2.4
−
Output high voltage,
POD = medium
V
DDP - 0.4
−
2.4
−
Output high voltage,
POD = strong
V
DDP - 0.4
−
IOH ≥ -1.4 mA
IOH ≥ -2 mA
2.4
−
−
Output low voltage,
POD = weak
VOLA2
CC
0.4
IOL ≤ 500 μA
Output low voltage,
POD = medium
−
−
0.4
0.4
V
V
IOL ≤ 2 mA
IOL ≤ 2 mA
Output low voltage,
POD = strong
Data Sheet
41
V1.0, 2013-01
Subject to Agreement on the Use of Product Information
