XMC4500
XMC4000 Family
Electrical Parameters
3.1.5
Operating Conditions
The following operating conditions must not be exceeded in order to ensure correct
operation and reliability of the XMC4500. All parameters specified in the following
sections refer to these operating conditions, unless noted otherwise.
Table 16
Operating Conditions Parameters
Symbol Values
Parameter
Unit Note /
Test Condition
Min.
Typ.
Max.
85
Ambient Temperature
TA SR -40
−
−
°C
°C
V
Temp. Range F
Temp. Range K
-40
125
3.63 2)
−
Digital supply voltage
Core Supply Voltage
V
DDP SR 3.131) 3.3
1)
VDDC
CC
−
1.3
V
Generated
internally
Digital ground voltage
VSS SR 0
DDA SR 3.0
−
−
3.62)
V
V
ADC analog supply
voltage
V
3.3
Analog ground voltage for VSSA SR -0.1
VDDA
0
0.1
V
V
Battery Supply Voltage for VBAT SR 1.95
−
3.63
When VDDP is
supplied VBAT
has to be
Hibernate Domain
supplied as
well.
System Frequency
fSYS SR −
ISC SR -5
−
−
120
5
MHz
mA
Short circuit current of
digital outputs
Absolute sum of short
circuit currents per pin
group3)
ΣISC_PG
SR
−
−
−
−
20
mA
mA
Absolute sum of short
circuit currents of the
device
ΣISC_D
SR
100
1) See also the Supply Monitoring thresholds, Section 3.3.2.
2) Voltage overshoot to 4.0 V is permissible at Power-Up and PORST low, provided the pulse duration is less
than 100 μs and the cumulated sum of the pulses does not exceed 1 h over lifetime.
3) The port groups are defined in Table 14.
Data Sheet
37
V1.0, 2013-01
