XMC4500
XMC4000 Family
Electrical Parameters
Table 20
Standard_Pads Class_A2 (cont’d)
Symbol Values
Max.
Parameter
Unit Note /
Test Condition
Min.
Fall time
t
FA2 CC
−
150
ns
ns
ns
CL = 20 pF;
POD = weak
−
−
50
CL = 50 pF;
POD = medium
3.7
CL = 50 pF;
POD = strong;
edge = sharp
−
−
7
ns
ns
CL = 50 pF;
POD = strong;
edge = medium
16
CL = 50 pF;
POD = strong;
edge = soft
Rise time
t
RA2 CC
−
−
−
150
50
ns
ns
ns
CL = 20 pF;
POD = weak
CL = 50 pF;
POD = medium
3.7
CL = 50 pF;
POD = strong;
edge = sharp
−
−
7.0
16
ns
ns
CL = 50 pF;
POD = strong;
edge = medium
CL = 50 pF;
POD = strong;
edge = soft
Data Sheet
42
V1.0, 2013-01
Subject to Agreement on the Use of Product Information
