XMC4500
XMC4000 Family
Electrical Parameters
Table 19
Standard_Pads Class_A1+ (cont’d)
Symbol Values
Max.
Parameter
Unit Note /
Test Condition
Min.
Output high voltage, VOHA1+
V
DDP - 0.4
−
V
V
V
V
V
V
V
IOH ≥ -400 μA
IOH ≥ -500 μA
IOH ≥ -1.4 mA
IOH ≥ -2 mA
POD1) = weak
CC
2.4
−
Output high voltage,
POD1) = medium
V
DDP - 0.4
−
2.4
−
Output high voltage,
POD1) = strong
V
DDP - 0.4
−
IOH ≥ -1.4 mA
IOH ≥ -2 mA
2.4
−
−
Output low voltage
VOLA1+
0.4
IOL ≤ 500 μA;
CC
POD1) = weak
−
−
−
−
−
0.4
0.4
150
50
V
IOL ≤ 2 mA;
POD1) = medium
V
IOL ≤ 2 mA;
POD1) = strong
Fall time
t
FA1+ CC
ns
ns
ns
CL = 20 pF;
POD1) = weak
CL = 50 pF;
POD1) = medium
28
CL = 50 pF;
POD1) = strong;
edge = slow
−
16
ns
CL = 50 pF;
POD1) = strong;
edge = soft;
Rise time
t
RA1+ CC
−
−
−
150
50
ns
ns
ns
CL = 20 pF;
POD1) = weak
CL = 50 pF;
POD1) = medium
28
CL = 50 pF;
POD1) = strong;
edge = slow
−
16
ns
CL = 50 pF;
POD1) = strong;
edge = soft
1) POD = Pin Out Driver
Data Sheet
40
V1.0, 2013-01
