XMC4500
XMC4000 Family
Electrical Parameters
3.1.2
Absolute Maximum Ratings
Stresses above the values listed under “Absolute Maximum Ratings” may cause
permanent damage to the device. This is a stress rating only and functional operation of
the device at these or any other conditions above those indicated in the operational
sections of this specification is not implied. Exposure to absolute maximum rating
conditions may affect device reliability.
Table 12
Absolute Maximum Rating Parameters
Symbol Values
Min. Typ. Max.
Parameter
Unit Note /
Test Con
dition
Storage temperature
Junction temperature
TST SR -65
TJ SR -40
–
−
–
150
150
4.3
°C
°C
V
–
–
–
Voltage at 3.3 V power supply VDDP SR
pins with respect to VSS
–
Voltage on any Class A and VIN
dedicated input pin with
respect to VSS
SR -0.5
–
V
DDP + 0.5
V
whichever
is lower
or max. 4.3
Voltage on any analog input VAIN
-0.5
–
–
–
V
DDP + 0.5
V
whichever
is lower
pin with respect to VAGND
VAREF SR
or max. 4.3
Input current on any pin
during overload condition
IIN
SR -10
+10
mA
mA
Absolute maximum sum of all ΣIIN SR -25
input circuit currents for one
port group during overload
condition1)
+25
Absolute maximum sum of all ΣIIN SR -100 –
input circuit currents during
+100
mA
overload condition
1) The port groups are defined in Table 14.
Data Sheet
34
V1.0, 2013-01
Subject to Agreement on the Use of Product Information
