XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
Summary of Features
Table 1
XC228x Derivative Synopsis
Derivative1)
Temp.
Range
Program
Memory
PSRAM2) CCU6 ADC3) Interfaces
Mod. Chan.
SAK-XC2287-
96F66L
-40 °C to 768Kbytes 64 Kbytes 0, 1,
125 °C Flash 2, 3
-40 °C to 576Kbytes 32 Kbytes 0, 1,
125 °C Flash 2, 3
-40 °C to 448Kbytes 16 Kbytes 0, 1,
125 °C Flash 2, 3
-40 °C to 768Kbytes 64 Kbytes 0, 1
125 °C Flash
-40 °C to 576Kbytes 32 Kbytes 0, 1
125 °C Flash
-40 °C to 448Kbytes 16 Kbytes 0, 1
125 °C Flash
-40 °C to 768Kbytes 64 Kbytes 0, 1
125 °C Flash
-40 °C to 576Kbytes 32 Kbytes 0, 1
125 °C Flash
-40 °C to 448Kbytes 16 Kbytes 0, 1
125 °C Flash
16 + 8 5 CAN Nodes,
6 Serial Chan.
SAK-XC2287-
72F66L
16 + 8 5 CAN Nodes,
6 Serial Chan.
SAK-XC2287-
56F66L
16 + 8 5 CAN Nodes,
6 Serial Chan.
SAK-XC2286-
96F66L
16 + 8 3 CAN Nodes,
6 Serial Chan.
SAK-XC2286-
72F66L
16 + 8 3 CAN Nodes,
6 Serial Chan.
SAK-XC2286-
56F66L
16 + 8 3 CAN Nodes,
6 Serial Chan.
SAK-XC2285-
96F66L
12
12
12
2 CAN Nodes,
4 Serial Chan.
SAK-XC2285-
72F66L
2 CAN Nodes,
4 Serial Chan.
SAK-XC2285-
56F66L
2 CAN Nodes,
4 Serial Chan.
1) This Data Sheet is valid for devices starting with and including design step AA.
2) All derivatives additionally provide 1 Kbyte SBRAM, 2 Kbytes DPRAM, and 16 Kbytes DSRAM.
3) Analog input channels are listed for each Analog/Digital Converter module separately.
