XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
Table 4
Functional Description
XC228x Interrupt Nodes
Source of Interrupt or PEC
Service Request
Control
Register
Vector
Trap
Number
Location1)
CAPCOM Register 16, or
ERU Request 0
CC2_CC16IC
CC2_CC17IC
CC2_CC18IC
CC2_CC19IC
CC2_CC20IC
CC2_CC21IC
CC2_CC22IC
CC2_CC23IC
CC2_CC24IC
CC2_CC25IC
CC2_CC26IC
CC2_CC27IC
CC2_CC28IC
CC2_CC29IC
xx’0040H
xx’0044H
xx’0048H
xx’004CH
xx’0050H
xx’0054H
xx’0058H
xx’005CH
xx’0060H
xx’0064H
xx’0068H
xx’006CH
xx’0070H
xx’0074H
10H / 16D
11H / 17D
12H / 18D
13H / 19D
14H / 20D
15H / 21D
16H / 22D
17H / 23D
18H / 24D
19H / 25D
1AH / 26D
1BH / 27D
1CH / 28D
1DH / 29D
CAPCOM Register 17, or
ERU Request 1
CAPCOM Register 18, or
ERU Request 2
CAPCOM Register 19, or
ERU Request 3
CAPCOM Register 20, or
USIC0 Request 6
CAPCOM Register 21, or
USIC0 Request 7
CAPCOM Register 22, or
USIC1 Request 6
CAPCOM Register 23, or
USIC1 Request 7
CAPCOM Register 24, or
ERU Request 0
CAPCOM Register 25, or
ERU Request 1
CAPCOM Register 26, or
ERU Request 2
CAPCOM Register 27, or
ERU Request 3
CAPCOM Register 28, or
USIC2 Request 6
CAPCOM Register 29, or
USIC2 Request 7
CAPCOM Register 30
CAPCOM Register 31
GPT1 Timer 2
CC2_CC30IC
CC2_CC31IC
xx’0078H
xx’007CH
1EH / 30D
1FH / 31D
20H / 32D
21H / 33D
22H / 34D
GPT12E_T2IC xx’0080H
GPT12E_T3IC xx’0084H
GPT12E_T4IC xx’0088H
GPT1 Timer 3
GPT1 Timer 4
Data Sheet
42
V0.91, 2007-02
Draft Version
