XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
Table 4
Functional Description
XC228x Interrupt Nodes (cont’d)
Source of Interrupt or PEC
Service Request
Control
Register
Vector
Trap
Number
Location1)
CAN Request 1
CAN Request 2
CAN Request 3
CAN Request 4
CAN Request 5
CAN Request 6
CAN Request 7
CAN Request 8
CAN Request 9
CAN Request 10
CAN Request 11
CAN Request 12
CAN Request 13
CAN Request 14
CAN Request 15
USIC0 Request 0
USIC0 Request 1
USIC0 Request 2
USIC0 Request 3
USIC0 Request 4
USIC0 Request 5
USIC1 Request 0
USIC1 Request 1
USIC1 Request 2
USIC1 Request 3
USIC1 Request 4
USIC1 Request 5
USIC2 Request 0
USIC2 Request 1
USIC2 Request 2
CAN_1IC
CAN_2IC
CAN_3IC
CAN_4IC
CAN_5IC
CAN_6IC
CAN_7IC
CAN_8IC
CAN_9IC
CAN_10IC
CAN_11IC
CAN_12IC
CAN_13IC
CAN_14IC
CAN_15IC
U0C0_0IC
U0C0_1IC
U0C0_2IC
U0C1_0IC
U0C1_1IC
U0C1_2IC
U1C0_0IC
U1C0_1IC
U1C0_2IC
U1C1_0IC
U1C1_1IC
U1C1_2IC
U2C0_0IC
U2C0_1IC
U2C0_2IC
xx’0104H
xx’0108H
xx’010CH
xx’0110H
xx’0114H
xx’0118H
xx’011CH
xx’0120H
xx’0124H
xx’0128H
xx’012CH
xx’0130H
xx’0134H
xx’0138H
xx’013CH
xx’0140H
xx’0144H
xx’0148H
xx’014CH
xx’0150H
xx’0154H
xx’0158H
xx’015CH
xx’0160H
xx’0164H
xx’0168H
xx’016CH
xx’0170H
xx’0174H
xx’0178H
41H / 65D
42H / 66D
43H / 67D
44H / 68D
45H / 69D
46H / 70D
47H / 71D
48H / 72D
49H / 73D
4AH / 74D
4BH / 75D
4CH / 76D
4DH / 77D
4EH / 78D
4FH / 79D
50H / 80D
51H / 81D
52H / 82D
53H / 83D
54H / 84D
55H / 85D
56H / 86D
57H / 87D
58H / 88D
59H / 89D
5AH / 90D
5BH / 91D
5CH / 92D
5DH / 93D
5EH / 94D
Data Sheet
44
V0.91, 2007-02
Draft Version
