TLE9879QXA40
Electrical Characteristics
29.1.3
Current Consumption
Table 19
Electrical Characteristics
VS = 5.5 V to 28 V, Tj = -40 °C to +150 °C; all voltages with respect to ground, positive current flowing into pin
(unless otherwise specified)
Parameter
Symbol
Values
Unit Note / Test Condition
Number
Min. Typ. Max.
Current Consumption @VS pin
Current consumption in IVs
–
30
35
mA
f
sys = 20 MHz
P_1.3.1
Active Mode at pin VS
no loads on pins, LIN in recessive
state1)
Current consumption in IVSD
Active Mode at pin VSD
–
–
–
40
35
mA 20 kHz
PWM on Bridge Driver
P_1.3.8
P_1.3.3
Current consumption in ISleep
Sleep Mode
30
µA System in Sleep Mode,
microcontrollernotpowered, Wake
capable via LIN and MON; MON
connected to VS or GND;
GPIOs open (no loads) or
connected to GND:
TJ = -40°C to 85°C;
VS = 5.5 V to 18V;2)
Current consumption in ISleep_exten
–
90
200
µA System in Sleep Mode,
microcontrollernotpowered, Wake
capable via LIN and MON; MON
connected to VS or GND;
GPIOs open (no loads) or
connected to GND:
P_1.3.15
Sleep Mode extended
d
range
TJ = -40°C to 150°C;
VS = 5.5 V to 18V;2)
Current consumption in ISleep
Sleep Mode
–
–
33
µA System in Sleep Mode,
microcontrollernotpowered, Wake
capable via LIN and MON; MON
connected to VS or GND;
GPIOs open (no loads) or
connected to GND:
P_1.3.9
TJ = -40°C to 40°C;
VS = 5.5 V to 18V;2)
Data Sheet
84
Rev. 1.0, 2015-04-30
