TLE9879QXA40
LIN Transceiver
20
LIN Transceiver
20.1
Features
General Functional Features
•
•
Compliant to LIN2.2 standard, backward compatible to LIN1.3, LIN2.0 and LIN 2.1
Compliant to SAE J2602 (slew rate, receiver hysteresis)
Special Features
•
•
•
Measurement of LIN master baudrate via Timer 2
LIN can be used as input/output with SFR bits.
TxD timeout feature (optional, on by default)
Operation Mode Features
•
•
•
•
LIN Sleep Mode (LSLM)
LIN Receive-Only Mode (LROM)
LIN Normal Mode (LNM)
High Voltage Input / Output Mode (LHVIO)
Supported Baud Rates
•
•
•
•
Mode for a transmission up to 10.4 kBaud
Mode for a transmission up to 20 kBaud
Mode for a transmission up to 40 kBaud
Mode for a transmission up to 115.2 kBaud
Slope Mode Features
•
•
•
Normal Slope Mode (20 kbit/s)
Low Slope Mode (10.4 kbit/s)
Flash Mode (115.2 kbit/s)
Wake-Up Features
LIN bus wake-up
•
Data Sheet
62
Rev. 1.0, 2015-04-30
