TLE9263QX
General Product Characteristics
4.4
Current Consumption
Table 4
Current Consumption
Current consumption values are specified at Tj = 25°C, VS = 13.5V, all outputs open (unless otherwise specified)
Parameter
Symbol
Values
Typ.
Unit Note / Test Condition Number
Min.
Max.
SBC Normal Mode
Normal Mode current
consumption
INormal
–
3.5
44
6.5
mA
µA
VS = 5.5 V to 28 V;
Tj = -40 °C to +150 °C;
VCC2, CAN, LIN,
P_4.4.1
VCC3, HSx = OFF
SBC Stop Mode
Stop Mode current
consumption
IStop_1,25
–
–
60
70
1)VCC2/3, HSx = OFF; P_4.4.2
CAN, LINx, WKx not
wake capable;
Watchdog = OFF;
no load on VCC1;
I_PEAK_TH = ‘0’
1)2)Tj = 85°C;
VCC2/3, HSx = OFF;
CAN, LINx, WKx not
wake capable;
Stop Mode current
consumption
IStop_1,85
50
µA
P_4.4.3
Watchdog = OFF;
no load on VCC1;
I_PEAK_TH = ‘0’
Stop Mode current
consumption
(high active peak threshold)
IStop_2,25
–
–
64
70
90
µA
µA
1)VCC2/3, HSx = OFF; P_4.4.35
CAN, LINx, WKx not
wake capable;
Watchdog = OFF;
no load on VCC1;
I_PEAK_TH = ‘1’
Stop Mode current
consumption
(high active peak threshold)
IStop_2,85
100
1)2)Tj = 85°C;
P_4.4.36
VCC2/3, HSx = OFF;
CAN, LINx, WKx not
wake capable;
Watchdog = OFF;
no load on VCC1;
I_PEAK_TH = ‘1’
SBC Sleep Mode
Sleep Mode current
consumption
ISleep,25
–
–
15
25
25
35
µA
µA
VCC2/3, HSx = OFF; P_4.4.5
CAN, LINx, WKx not
wake capable
Sleep Mode current
consumption
ISleep,85
2)Tj = 85°C;
P_4.4.6
VCC2/3, HSx = OFF;
CAN, LINx, WKx not
wake capable
Data Sheet
16
Rev. 1.1, 2014-09-26
