TLE 6244X
1.6.2 Diagnostics/Encoding of Failures
Description of the SPI Registers
(SPI Instructions: RD_DIA1...5)
Register: DIA_REG1
7
6
5
4
3
2
1
0
DIA7
DIA6
DIA5
DIA4
DIA3
DIA2
DIA1
DIA0
State of Reset: FFH
Access by Controller: Read only
Bit
1-0
3-2
5-4
7-6
Name
Description
DIA (1-0)
DIA (3-2)
DIA (5-4)
DIA (7-6)
Diagnostic Bits of power stage 1
Diagnostic Bits of power stage 2
Diagnostic Bits of power stage 3
Diagnostic Bits of power stage 4
Register: DIA_REG2
7
6
5
4
3
2
1
0
DIA15
DIA14
DIA13
DIA12
DIA11
DIA10
DIA9
DIA8
State of Reset: FFH
Access by Controller: Read only
Bit
1-0
3-2
5-4
7-6
Name
Description
DIA (9-8)
DIA (11-10)
DIA (13-12)
DIA (15-14)
Diagnostic Bits of power stage 5
Diagnostic Bits of power stage 6
Diagnostic Bits of power stage 7
Diagnostic Bits of power stage 8
Final Data Sheet
17
V4.2, 2003-08-29
