TLE 6244X
Register: DIA_REG5
7
6
5
1
4
3
2
1
0
1
1
UBatt
DIA35
DIA34
DIA33
DIA32
State of Reset: FFH
Access by Controller: Read only
Bit
1-0
3-2
4
Name
Description
DIA (33-32)
DIA (35-34)
UBatt
Diagnostic Bits of power stage 17
Diagnostic Bits of power stage 18
0: Voltage Level at Pin UBatt is below 2V (typically)
1: Voltage Level at Pin UBatt is above 2V (typically)
Diagnosis of UBatt is only possible if U
Status of UBatt is not latched.
> 4.5V
VDD
7-5
No function: High on reading
Encoding of the Diagnostic Bits of the Power Stages
DIA(2*x-1)
DIA(2*x-2)
State of power stage x
Power stage o.k.
x = 1..18
1
1
0
0
1
0
1
0
Short-circuit to UBatt (SCB) / OT
Open load (OL)
Short-circuit to ground (SCG)
Final Data Sheet
19
V4.2, 2003-08-29
