TLE 6244X
Register: SCON_REG1
7
6
5
4
3
2
1
0
SCON7
SCON6
SCON5
SCON4
SCON3
SCON2
SCON1
SCON0
State of Reset: FFH
Access by Controller: Read/Write
Bit
0
Name
Description
SCON0
SCON1
SCON2
SCON3
SCON4
SCON5
SCON6
SCON7
State of serial control of power stage 1
State of serial control of power stage 2
State of serial control of power stage 3
State of serial control of power stage 4
State of serial control of power stage 5
State of serial control of power stage 6
State of serial control of power stage 7
State of serial control of power stage 8
1
2
3
4
5
6
7
Register: SCON_REG2
7
6
5
4
3
2
1
0
SCON15
SCON14
SCON13
SCON12
SCON11
SCON10
SCON9
SCON8
State of Reset: FFH
Access by Controller: Read/Write
Bit
0
Name
Description
State of serial control of power stage 9
SCON8
SCON9
SCON10
SCON11
SCON12
SCON13
SCON14
SCON15
1
State of serial control of power stage 10
State of serial control of power stage 11
State of serial control of power stage 12
State of serial control of power stage 13
State of serial control of power stage 14
State of serial control of power stage 15
State of serial control of power stage 16
2
3
4
5
6
7
Final Data Sheet
15
V4.2, 2003-08-29
