TDA5235
Appendix
Register Description
Field
Bits
Type
Description
UNUSED
6:4
-
UNUSED
Reset: 0H
AGCMANF
3
wc
AGC Manual Freeze
When *_AGCSFCFG.AGCFREEZE set to SPI Command, this bit sets the
AGC to freeze mode
0B
1B
Inactive
Active
Reset: 0H
AFCMANF
2
wc
AFC Manual Freeze
When *_AFCSFCFG.AFCFREEZE set to SPI Command, this bit sets the
AFC to freeze mode
0B
1B
Inactive
Active
Reset: 0H
EXTTOTIM
EXTEOM
1
0
wc
wc
Force TOTIM signal in external data processing mode
(*_CHCFG.EXTROC = 1H or 2H)
0B
1B
no external TOTIM signal forced
external TOTIM signal forced
Reset: 0H
Force EOM signal in external data processing mode
(*_CHCFG.EXTROC = 1H or 2H)
0B
1B
no external EOM signal forced
external EOM signal forced
Reset: 0H
Chip Mode Control Register 1
CMC1
Offset
0A5H
Reset Value
04H
Chip Mode Control Register 1
ꢀ
ꢃ
ꢈ
ꢄ
ꢅ
ꢆ
ꢇ
),)2/.
Z
ꢁ
(20ꢂ1&)
*
727,0ꢂ1
&+
,1,7),)
2
)6,1,7)
,)2
;7$/+30
6
8186('
ꢂ
Z
Z
Z
Z
Z
Field
Bits
Type
Description
UNUSED
7:6
-
UNUSED
Reset: 0H
EOM2NCFG
5
w
Continue with next Configuration in Self Polling Mode after EOM
detected in Run Mode Self Polling
0B
1B
Continue with Configuration A in Self Polling Mode
Continue with next Configuration in Self Polling Mode
Reset: 0H
Data Sheet
245
V1.0, 2010-02-19
