TDA5235
Appendix
Register Description
Field
Bits
Type
Description
SPMONTA0
7:0
w
Set Value Self Polling Mode On Time: SPMONTA(13:0) =
SPMONTA1(MSB) & SPMONTA0(LSB)
On-Time = TRT *SPMONTA
Min: 0001h = 1*TRT
Reg.Value: 3FFFh = 16383*TRT
Max: 0000h = 16384*TRT
Reset: 01H
Self Polling Mode On Time Config A Register 1
SPMONTA1
Offset
09DH
Reset Value
00H
Self Polling Mode On Time Config A Register
1
ꢀ
ꢃ
ꢈ
ꢁ
8186('
630217$ꢁ
ꢂ
Z
Field
Bits
Type
Description
UNUSED
7:6
-
UNUSED
Reset: 0H
SPMONTA1
5:0
w
Set Value Self Polling Mode On Time: SPMONTA(13:0) =
SPMONTA1(MSB) & SPMONTA0(LSB)
On-Time = TRT *SPMONTA
Min: 0001h = 1*TRT
Reg.Value: 3FFFh = 16383*TRT
Max: 0000h = 16384*TRT
Reset: 00H
Self Polling Mode On Time Config B Register 0
SPMONTB0
Offset
09EH
Reset Value
01H
Self Polling Mode On Time Config B Register
0
ꢀ
ꢁ
630217%ꢀ
Z
Data Sheet
243
V1.0, 2010-02-19
