TDA5235
Appendix
Register Description
Field
Bits
Type
Description
UNUSED
7:5
-
UNUSED
Reset: 0H
SPMAP
4:0
w
Self Polling Mode Active Periods value
Min: 01h = 1 (Master) Period
Max: 1Fh = 31(Master) Periods
Reg. value 00h = 32 (Master) Periods
Reset: 01H
Self Polling Mode Idle Periods Register
SPMIP
Offset
097H
Reset Value
01H
Self Polling Mode Idle Periods Register
ꢀ
ꢁ
630,3
Z
Field
Bits
Type
Description
SPMIP
7:0
w
Self Polling Mode Idle Periods value
Min: 01h = 1 (Master) Period
Max: FFh = 255 (Master) Periods
Reg. value 00h = 256 (Master) Periods
Reset: 01H
Self Polling Mode Control Register
SPMC
Offset
098H
Reset Value
00H
Self Polling Mode Control Register
ꢀ
ꢅ
ꢆ
630$,(1
Z
ꢇ
ꢁ
8186('
6306(/
ꢂ
Z
Field
Bits
Type
Description
UNUSED
7:3
-
UNUSED
Reset: 00H
Data Sheet
240
V1.0, 2010-02-19
