TDA5235
Appendix
Register Description
Field
Bits
Type
Description
PMFDN
2:0
w
Peak Memory Filter Decay (Down) Factor (additional to Attack
Factor)
000B 2^-2
001B 2^-3
010B 2^-4
011B 2^-5
100B 2^-6
101B 2^-7
110B 2^-8
111B 2^-9
Reset: 2H
AGC Start/Freeze Configuration Register
A_AGCSFCFG
Offset
032H
Reset Value
00H
AGC Start/Freeze Configuration Register
ꢀ
ꢃ
ꢈ
ꢄ
ꢆ
ꢇ
ꢁ
$*&5(6$
7&&
8186('
$*&)5((=(
$*&67$57
ꢂ
Z
Z
Z
Field
Bits
Type
Description
UNUSED
7:6
-
UNUSED
Reset: 0H
AGCRESATC
C
5
w
Enable AGC Restart at the beginning of the current configuration in
Self Polling Mode
and at leaving the HOLD state (when bit CMC0.INITPLLHOLD is set) in
Run Mode Slave
0B
1B
Disabled
Enabled
Reset: 0H
AGCFREEZE 4:2
w
AGC Freeze Configuration
When selecting a Level criterion here,
please note to use the same Level criterion as for Wake-Up
000B Stay ON
001B Freeze on RSSI Event + Delay (AFCAGCDEL)
010B Freeze on Signal Recognition Event + Delay (AFCAGCDEL)
011B Freeze on Symbol Synchronization + Delay (AFCAGCDEL)
100B SPI Command - write to EXTPCMD.AGCMANF bit
101B n.u.
110B n.u.
111B n.u.
Reset: 0H
Data Sheet
200
V1.0, 2010-02-19
