TDA5235
Appendix
Register Description
A_AFCK2CFG1
Offset
030H
Reset Value
00H
AFC Integrator 2 Gain Register 1
ꢀ
ꢄ
ꢅ
ꢁ
8186('
$)&.ꢂBꢁ
ꢂ
Z
Field
Bits
Type
Description
UNUSED
7:4
-
UNUSED
Reset: 0H
AFCK2_1
3:0
w
AFC Filter coefficient K2, AFCK2(11:0) = AFCK2_1(MSB) &
AFCK2_0(LSB)
Reset: 0H
Peak Memory Filter Up-Down Factor Register
A_PMFUDSF
Offset
031H
Reset Value
42H
Peak Memory Filter Up-Down Factor Register
ꢀ
ꢃ
ꢄ
ꢅ
ꢆ
ꢁ
8186('
30)83
8186('
30)'1
ꢂ
Z
ꢂ
Z
Field
Bits
Type
Description
UNUSED
7
-
UNUSED
Reset: 0H
PMFUP
6:4
w
Peak Memory Filter Attack (Up) Factor
000B 2^-1
001B 2^-2
010B 2^-3
011B 2^-4
100B 2^-5
101B 2^-6
110B 2^-7
111B 2^-8
Reset: 4H
UNUSED
3
-
UNUSED
Reset: 0H
Data Sheet
199
V1.0, 2010-02-19
