TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-10 Port 20 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
K22
P20.9
I
FAST /
PU1 /
VEXT /
ES
General-purpose input
GTM_TIM6_IN3_1
GTM_TIM3_IN5_5
GTM_TIM2_IN5_5
CAN03_RXDE
ASCLIN1_ARXC
QSPI0_SLSIB
SCU_E_REQ7_0
Mux input channel 3 of TIM module 6
Mux input channel 5 of TIM module 3
Mux input channel 5 of TIM module 2
CAN receive input node 3
Receive input
Slave select input
ERU Channel 7 inputs 0 to 5 (0 is the LSB and 5 is the
MSB)
P20.9
O0
O1
O2
O3
O4
O5
O6
O7
General-purpose output
GTM muxed output
Reserved
GTM_TOUT65
—
QSPI0_SLSO1
QSPI1_SLSO1
—
Master slave select output
Master slave select output
Reserved
—
Reserved
CCU61_CC61
IOM_MON1_9
IOM_REF1_12
P20.10
T12 PWM channel 61
Monitor input 1
Reference input 1
K24
I
FAST /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 6 of TIM module 3
Mux input channel 6 of TIM module 2
read data in
GTM_TIM3_IN6_6
GTM_TIM2_IN6_6
SDMMC0_DAT2_IN
P20.10
O0
O1
O2
General-purpose output
GTM muxed output
Transmit output
GTM_TOUT66
ASCLIN1_ATX
IOM_MON2_13
IOM_REF2_13
QSPI0_SLSO6
QSPI2_SLSO7
CAN03_TXD
IOM_MON2_8
IOM_REF2_8
ASCLIN1_ASCLK
CCU61_CC62
IOM_MON1_10
IOM_REF1_11
SDMMC0_DAT2
Monitor input 2
Reference input 2
O3
O4
O5
Master slave select output
Master slave select output
CAN transmit output node 3
Monitor input 2
Reference input 2
O6
O7
Shift clock output
T12 PWM channel 62
Monitor input 1
Reference input 1
O
write data out
Data Sheet
92
V 1.2, 2021-03
