TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-10 Port 20 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
J25
P20.13
I
FAST /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 1 of TIM module 3
Mux input channel 1 of TIM module 2
Slave select input
read data in
GTM_TIM3_IN1_4
GTM_TIM2_IN1_4
QSPI0_SLSIA
SDMMC0_DAT5_IN
IOM_PIN_14
P20.13
GPIO pad input to FPC
General-purpose output
GTM muxed output
Monitor input 0
O0
O1
GTM_TOUT69
IOM_MON0_14
O2
O3
O4
O5
O6
O7
Reserved
QSPI0_SLSO2
QSPI1_SLSO2
QSPI0_SCLK
Master slave select output
Master slave select output
Master SPI clock output
Reserved
CCU61_COUT62
IOM_MON1_13
IOM_REF1_8
SDMMC0_DAT5
P20.14
T12 PWM channel 62
Monitor input 1
Reference input 1
O
I
write data out
H25
FAST /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 2 of TIM module 3
Mux input channel 2 of TIM module 2
Slave SPI data input
read data in
GTM_TIM3_IN2_4
GTM_TIM2_IN2_4
QSPI0_MTSRA
SDMMC0_DAT6_IN
IOM_PIN_15
P20.14
GPIO pad input to FPC
General-purpose output
GTM muxed output
Monitor input 0
O0
O1
GTM_TOUT70
IOM_MON0_15
O2
O3
O4
O5
O6
O7
O
Reserved
QSPI0_MTSR
Master SPI data output
Reserved
Reserved
Reserved
Reserved
SDMMC0_DAT6
write data out
Data Sheet
94
V 1.2, 2021-03
OPEN MARKET VERSION
