TC39x BC/BD-Step
Electrical SpecificationJTAG Parameters
3.19
JTAG Parameters
The following parameters are applicable for communication through the JTAG debug interface. The JTAG module
is fully compliant with IEEE1149.1-2000.
Table 3-38 JTAG
Parameter
Symbol
Values
Typ.
Unit
Note / Test Condition
Min.
50
10
10
-
Max.
TCK clock period
TCK high time
t1 SR
t2 SR
t3 SR
t4 SR
t5 SR
t6 SR
-
-
-
-
-
-
-
ns
ns
ns
ns
ns
ns
-
TCK low time
-
TCK clock rise time
TCK clock fall time
4
4
-
-
TDI/TMS setup to TCK rising
edge
6.0
TDI/TMS hold after TCK rising t7 SR
6.0
-
-
ns
edge
TDO valid after TCK falling edge t8 CC
(propagation delay)
3.0
-
-
-
-
-
ns
ns
ns
ns
CL≤20pF
CL≤50pF
-
25
-
TDO hold after TCK falling edge t18 CC
2
-
TDO high impedance to valid
from TCK falling edge
t9 CC
25
CL≤50pF
CL≤50pF
TDO valid output to high
impedance from TCK falling
edge
t
10 CC
-
-
25
ns
t1
0.9 VEXT
0.1 VEXT
0.5 VEXT
t5
t4
t2
t3
MC_JTAG_TCK
Figure 3-10 Test Clock Timing (TCK)
Data Sheet
476
V 1.2, 2021-03
OPEN MARKET VERSION
