SAK-TC399XP-256F300S BC 参数 Datasheet PDF下载

SAK-TC399XP-256F300S BC图片预览
型号: SAK-TC399XP-256F300S BC
PDF下载: 下载PDF文件 查看货源
内容描述: [Infineon releases its second generation AURIX microcontroller in embedded flash 40 nm technology. It comes back with an increase in performance, memory sizes, connectivity and more scalability to address the new automotive trends and challenges. This family has more than 20 products to provide the most scalable portfolio of safety microcontrol­ler. In terms of performance, the highest end product TC39x offers 6 cores running at 300 MHz and up to 6.9 MBytes embedded RAM, and consuming below 2 W. ]
分类和应用:
文件页数/大小: 548 页 / 21256 K
品牌: INFINEON [ Infineon ]
 浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第469页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第470页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第471页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第472页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第474页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第475页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第476页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第477页
TC39x BC/BD-Step
Electrical SpecificationSystem Phase Locked Loop (SYS_PLL)
3.16
System Phase Locked Loop (SYS_PLL)
Table 3-36 PLL System
Parameter
Symbol
Values
Typ.
Unit
Note / Test Condition
Min.
10
Max.
40
DCO Input frequency range
Modulation Amplitude
Peak Period jitter
f
REF CC
-
-
-
MHz
%
MA CC
DP CC
0
2
-200
200
ps
without modulation
(PLL output frequency)
Peak Accumulated Jitter
Total long term jitter
D
PP CC
-5
-
-
-
5
ns
ns
without modulation
J
TOT CC
11.5
including modulation;
MA 1.25%; fREF 20MHz
System frequency deviation
DCO frequency range
PLL lock-in time
f
f
SYSD CC
DCO CC
-
-
-
-
0.01
800
100
%
with active modulation
400
4
MHz
µs
tL CC
Note:The specified PLL jitter values are valid if the capacitive load per pin does not exceed CL = 20 pF with the
maximum driver and sharp edge.
Note:The maximum peak-to-peak noise on the power supply voltage, is limited to a peak-to-peak voltage of
V
PP = 100 mV for noise frequencies below 300 KHz and VPP = 40 mV for noise frequencies above 300 KHz.
These conditions can be achieved by appropriate blocking of the supply voltage as near as possible to the
supply pins and using PCB supply and ground planes.
Data Sheet
473
V 1.2, 2021-03
OPEN MARKET VERSION
