TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-22 Analog Inputs (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
W7
AN37/P40.7
I
I
I
S / HighZ Analog Input 37
/ VDDM
SENT_SENT7A
EVADC_G8CH5
CCU61_CCPOS1D
EDSADC_EDS1NA
AN38/P40.8
Receive input channel 7
Analog input channel 5, group 8
Hall capture input 1
Negative analog input channel 1, pin A
V10
W6
S / HighZ Analog Input 38
/ VDDM
SENT_SENT8A
EVADC_G8CH6
CCU61_CCPOS2B
EDSADC_EDS1PB
AN39/P40.9
Receive input channel 8
Analog input channel 6, group 8
Hall capture input 2
Positive analog input channel 1, pin B
S / HighZ Analog Input 39
/ VDDM
SENT_SENT9A
EVADC_G8CH7
CCU61_CCPOS2D
EDSADC_EDS1NB
AN40
Receive input channel 9
Analog input channel 7, group 8
Hall capture input 2
Negative analog input channel 1, pin B
U10
U9
T10
T9
I
I
I
I
I
I
I
D / HighZ Analog Input 40
/ VDDM
EVADC_G8CH8
EVADC_G4CH0
AN41
Analog input channel 8, group 8
Analog input channel 0, group 4
D / HighZ Analog Input 41
/ VDDM
EVADC_G8CH9
EVADC_G4CH1
AN42
Analog input channel 9, group 8
Analog input channel 1, group 4
D / HighZ Analog Input 42
/ VDDM
EVADC_G8CH10
EVADC_G4CH2
AN43
Analog input channel 10, group 8
Analog input channel 2, group 4
D / HighZ Analog Input 43
/ VDDM
EVADC_G8CH11
EVADC_G4CH3
AN44
Analog input channel 11, group 8
Analog input channel 3, group 4
D / HighZ Analog Input 44
V6
/ VDDM
EVADC_G8CH12
EDSADC_EDS1PC
AN45
Analog input channel 12, group 8
Positive analog input channel 1, pin C
V7
D / HighZ Analog Input 45
/ VDDM
EVADC_G8CH13
EDSADC_EDS1NC
AN46
Analog input channel 13, group 8
Negative analog input channel 1, pin C
D / HighZ Analog Input 46
U6
/ VDDM
EVADC_G8CH14
EDSADC_EDS1PD
Analog input channel 14, group 8
Positive analog input channel 1, pin D
