TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-22 Analog Inputs (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
AD9
AN18/P40.11
I
S / HighZ Analog Input 18
/ VDDM
SENT_SENT11A
EVADC_G11CH8
EVADC_G2CH2
AN19/P40.12
Receive input channel 11
Analog input channel 8, group 11
Analog input channel 2, group 2
AD8
I
S / HighZ Analog Input 19
/ VDDM
SENT_SENT12A
EVADC_G11CH9
EVADC_G2CH3
AN20
Receive input channel 12
Analog input channel 9, group 11
Analog input channel 3, group 2
AE8
AE7
I
I
D / HighZ Analog Input 20
/ VDDM
EVADC_G2CH4
EDSADC_EDS2PA
AN21
Analog input channel 4, group 2
Positive analog input channel 2, pin A
D / HighZ Analog Input 21
/ VDDM
EVADC_G2CH5
EDSADC_EDS2NA
Analog input channel 5, group 2
Negative analog input channel 2, pin A
AA10 AN22
EVADC_G2CH6
AN23
I
I
I
D / HighZ Analog Input 22
/ VDDM
Analog input channel 6, group 2
Y10
AD7
D / HighZ Analog Input 23
/ VDDM
EVADC_G2CH7
AN24/P40.0
Analog input channel 7, group 2
S / HighZ Analog Input 24
/ VDDM
SENT_SENT0A
EVADC_G3CH0
CCU60_CCPOS0D
EDSADC_EDS2PB
AN25/P40.1
Receive input channel 0
Analog input channel 0, group 3
Hall capture input 0
Positive analog input channel 2, pin B
AD6
AC7
AC6
I
I
I
S / HighZ Analog Input 25
/ VDDM
SENT_SENT1A
EVADC_G3CH1
CCU60_CCPOS1B
EDSADC_EDS2NB
AN26/P40.2
Receive input channel 1
Analog input channel 1, group 3
Hall capture input 1
Negative analog input channel 2, pin B
S / HighZ Analog Input 26
/ VDDM
SENT_SENT2A
EVADC_G3CH2
CCU60_CCPOS1D
EVADC_G11CH10
AN27/P40.3
Receive input channel 2
Analog input channel 2, group 3
Hall capture input 1
Analog input channel 10, group 11
S / HighZ Analog Input 27
/ VDDM
SENT_SENT3A
EVADC_G3CH3
CCU60_CCPOS2B
EVADC_G11CH11
Receive input channel 3
Analog input channel 3, group 3
Hall capture input 2
Analog input channel 11, group 11
Data Sheet
163
V 1.2, 2021-03
