TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-22 Analog Inputs (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
AB7
AN28/P40.13
I
S / HighZ Analog Input 28
/ VDDM
SENT_SENT13A
EVADC_G3CH4
EVADC_G4CH4
AN29/P40.14
Receive input channel 13
Analog input channel 4, group 3
Analog input channel 4, group 4
AB6
I
S / HighZ Analog Input 29
/ VDDM
SENT_SENT14A
EVADC_G3CH5
EVADC_G4CH5
AN30
Receive input channel 14
Analog input channel 5, group 3
Analog input channel 5, group 4
AA9
Y9
I
I
I
D / HighZ Analog Input 30
/ VDDM
EVADC_G3CH6
EVADC_G4CH6
AN31
Analog input channel 6, group 3
Analog input channel 6, group 4
D / HighZ Analog Input 31
/ VDDM
EVADC_G3CH7
EVADC_G4CH7
AN32/P40.4
Analog input channel 7, group 3
Analog input channel 7, group 4
W9
S / HighZ Analog Input 32
/ VDDM
SENT_SENT4A
EVADC_G8CH0
CCU60_CCPOS2D
EVADC_G11CH12
AN33/P40.5
Receive input channel 4
Analog input channel 0, group 8
Hall capture input 2
Analog input channel 12, group 11
Y6
I
S / HighZ Analog Input 33
/ VDDM
SENT_SENT5A
EVADC_G8CH1
CCU61_CCPOS0D
EVADC_G11CH13
AN34
Receive input channel 5
Analog input channel 1, group 8
Hall capture input 0
Analog input channel 13, group 11
W10
Y7
I
I
I
D / HighZ Analog Input 34
/ VDDM
EVADC_G8CH2
EVADC_G11CH14
AN35
Analog input channel 2, group 8
Analog input channel 14, group 11
D / HighZ Analog Input 35
/ VDDM
EVADC_G8CH3
EVADC_G11CH15
AN36/P40.6
Analog input channel 3, group 8
Analog input channel 15, group 11
V9
S / HighZ Analog Input 36
/ VDDM
SENT_SENT6A
EVADC_G8CH4
CCU61_CCPOS1B
EDSADC_EDS1PA
Receive input channel 6
Analog input channel 4, group 8
Hall capture input 1
Positive analog input channel 1, pin A
