TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-21 Port 34 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
AB17 P34.3
GTM_TIM5_IN5_10
I
SLOW /
PU1 /
VEVRSB
/ ES
General-purpose input
Mux input channel 5 of TIM module 5
Mux input channel 6 of TIM module 3
Mux input channel 5 of TIM module 2
Analog input channel 9, group 10
General-purpose output
GTM muxed output
GTM_TIM3_IN6_13
GTM_TIM2_IN5_9
EVADC_G10CH9
P34.3
AI
O0
O1
O2
O3
O4
O5
O6
O7
GTM_TOUT148
ASCLIN4_ASCLK
—
Shift clock output
Reserved
QSPI2_SLSO10
—
Master slave select output
Reserved
—
Reserved
CCU60_COUT60
IOM_MON1_3
IOM_REF1_3
T12 PWM channel 60
Monitor input 1
Reference input 1
AA18 P34.4
I
SLOW /
PU1 /
VEVRSB
/ ES
General-purpose input
Mux input channel 6 of TIM module 5
Mux input channel 7 of TIM module 3
Mux input channel 6 of TIM module 2
Master SPI data input
Analog input channel 8, group 10
General-purpose output
GTM muxed output
GTM_TIM5_IN6_10
GTM_TIM3_IN7_12
GTM_TIM2_IN6_8
QSPI2_MRSTD
EVADC_G10CH8
P34.4
AI
O0
O1
O2
O3
O4
GTM_TOUT149
ASCLIN4_ASLSO
—
Slave select signal output
Reserved
QSPI2_MRST
IOM_MON2_2
IOM_REF2_2
—
Slave SPI data output
Monitor input 2
Reference input 2
O5
O6
O7
Reserved
EVADC_FC6BFLOUT
CCU60_CC61
IOM_MON1_1
IOM_REF1_5
Boundary flag output, FC channel 6
T12 PWM channel 61
Monitor input 1
Reference input 1
Data Sheet
160
V 1.2, 2021-03
OPEN MARKET VERSION
