C167CR
C167SR
Table 3
C167CR Interrupt Nodes
Source of Interrupt or Request
PEC Service Request Flag
Enable
Flag
Interrupt Vector
Trap
Vector
Location Number
00’0040H 10H
00’0044H 11H
00’0048H 12H
00’004CH 13H
00’0050H 14H
00’0054H 15H
00’0058H 16H
00’005CH 17H
00’0060H 18H
00’0064H 19H
CAPCOM Register 0
CAPCOM Register 1
CAPCOM Register 2
CAPCOM Register 3
CAPCOM Register 4
CAPCOM Register 5
CAPCOM Register 6
CAPCOM Register 7
CAPCOM Register 8
CAPCOM Register 9
CC0IR
CC1IR
CC2IR
CC3IR
CC4IR
CC5IR
CC6IR
CC7IR
CC8IR
CC9IR
CC0IE
CC0INT
CC1INT
CC2INT
CC3INT
CC4INT
CC5INT
CC6INT
CC7INT
CC8INT
CC9INT
CC1IE
CC2IE
CC3IE
CC4IE
CC5IE
CC6IE
CC7IE
CC8IE
CC9IE
CAPCOM Register 10 CC10IR
CAPCOM Register 11 CC11IR
CAPCOM Register 12 CC12IR
CAPCOM Register 13 CC13IR
CAPCOM Register 14 CC14IR
CAPCOM Register 15 CC15IR
CAPCOM Register 16 CC16IR
CAPCOM Register 17 CC17IR
CAPCOM Register 18 CC18IR
CAPCOM Register 19 CC19IR
CAPCOM Register 20 CC20IR
CAPCOM Register 21 CC21IR
CAPCOM Register 22 CC22IR
CAPCOM Register 23 CC23IR
CAPCOM Register 24 CC24IR
CAPCOM Register 25 CC25IR
CAPCOM Register 26 CC26IR
CAPCOM Register 27 CC27IR
CAPCOM Register 28 CC28IR
CAPCOM Register 29 CC29IR
CC10IE
CC11IE
CC12IE
CC13IE
CC14IE
CC15IE
CC16IE
CC17IE
CC18IE
CC19IE
CC20IE
CC21IE
CC22IE
CC23IE
CC24IE
CC25IE
CC26IE
CC27IE
CC28IE
CC29IE
CC10INT 00’0068H 1AH
CC11INT 00’006CH 1BH
CC12INT 00’0070H 1CH
CC13INT 00’0074H 1DH
CC14INT 00’0078H 1EH
CC15INT 00’007CH 1FH
CC16INT 00’00C0H 30H
CC17INT 00’00C4H 31H
CC18INT 00’00C8H 32H
CC19INT 00’00CCH 33H
CC20INT 00’00D0H 34H
CC21INT 00’00D4H 35H
CC22INT 00’00D8H 36H
CC23INT 00’00DCH 37H
CC24INT 00’00E0H 38H
CC25INT 00’00E4H 39H
CC26INT 00’00E8H 3AH
CC27INT 00’00ECH 3BH
CC28INT 00’00E0H 3CH
CC29INT 00’0110H 44H
Data Sheet
19
V3.2, 2001-07
