PEB 2091
PEF 2091
Electrical Characteristics
8.4
Power Consumption
The power consumption of version 5.3 has been reduced, compared with version 5.1.
Version 5.3 will have the same power consumption values as version 5.2.
All measurements with random 2B + D data in active states.
Mode
Test Conditions
Limit Values
Unit
typ.
max.
Power up
5.00 V, open outputs
98 Ω load at AOUT/BOUT
Inputs at VDD/GND
53.0
59.0
mA
LT-Power down
5.00 V, open outputs
98 Ω load at AOUT/BOUT
Temperature ≥ 0°C
6.7
8.0
4.7
6.5
11.0
mA
mA
mA
mA
Inputs at VDD/GND
5.00 V, open outputs
98 Ω load at AOUT/BOUT
Temperature < 0°C
13.0
9.0
Inputs at VDD/GND
NT-Power down
5.00 V, open outputs
98 Ω load at AOUT/BOUT
Temperature ≥ 0°C
Inputs at VDD/GND
5.00 V, open outputs
98 Ω load at AOUT/BOUT
Temperature < 0°C
11.0
Inputs at VDD/GND
Note 78: The power consumption specified above includes the power dissipation
in the load resistance. The power dissipation in the IEC-Q itself is 7.5 mA
less in the active state, i.e. the maximum internal power dissipation of
the IEC-Q in the active state is less than 52 mA, under the stated
conditions.
