PEB 2091
PEF 2091
Electrical Characteristics
8.5
Analog Characteristics
Limit Values
min.
typ.
max.
Unit
Receive Path
Signal / N+D
60
65
dB
(noise + total harmonic distortion)1)
2)
DC-level at AD-output
Threshold of level detect
Input impedance AIN/BIN
Transmit Path
45
4
50
20
55
28
%
mV
50
kΩ
Signal / N+D
65
70
dB
(noise + total harmonic distortion)3)
Output DC-level
2.05
2.375
2.6
dB
mV
V
Offset between AOUT and BOUT
Signal amplitude4)
35.5
3.30
3.10
3.20
Output impedance AOUT/BOUT:
Power-up
Power-down
2
6
4
12
Ω
Ω
1) Test conditions: 1.3 Vpp antisemetric sine wave as input on AIN/BIN with long range (low, critical range)
2) The percentage of the "1"-values in the PDM-signal
3) Interpretation and test conditions: The sum of noise and total harmonic distortion,
weighted with a low pass filter 0 to 80 kHz, is at least 65 dB below the signal for an
evenly distributed but otherwise random sequence of + 3, + 1, – 1, – 3
4) The signal amplitude measured over a period of 1 min. varies less than 1%
