Control Integrated POwer System (CIPOS™)
IFCM15P60GD
Thermistor
Value
typ
Description
Condition
TNTC = 25°C
Symbol
Unit
min
-
max
-
Resistor
RNTC
85
k
B-constant of NTC
(Negative temperature coefficient)
B(25/100)
-
4092
-
K
3500
35
Min.
Typ.
Max.
3000
2500
2000
1500
1000
500
30
25
20
15
10
5
0
50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130
Thermistor temperature [℃]
0
-40 -30 -20 -10
0
10 20 30 40 50 60 70 80 90 100 110 120 130
Thermistor temperature [℃]
Figure 7
Thermistor resistance – temperature curve and table
(For more information, please refer to the application note ‘AN CIPOS™-Mini 1 Technical description’)
Mechanical Characteristics and Ratings
Value
Description
Condition
Unit
min
0.49
-50
-
typ
max
Mounting torque
M3 screw and washer
Refer to Figure 8
-
-
0.78
100
-
Nm
µm
g
Flatness
Weight
6.83
Figure 8
Flatness measurement position
Datasheet
13 of 18
V 2.2
2017-09-06
