CCM-PFC
ICE2PCS06/G
Functional Description
VCC
Gate Driver
PWM Logic
HIGH to
turn on
LV
Z1
External
MOS
GATE
* LV: Level Shift
ICE2PCS06/G
Figure 15 Gate Driver
The output is active HIGH and at VCC voltages below the under voltage lockout threshold VCCUVLO, the gate drive
is internally pull low to maintain the off state.
Version 1.1
12
Mar 2010
