IDT72T7285/72T7295/72T72105/72T72115 2.5V TeraSync
16,384 x 72, 32,768 x 72, 65,536 x 72, 131,072 x 72
72-BIT FIFO
COMMERCIAL AND INDUSTRIAL
TEMPERATURE RANGES
PARTIAL RESET (PRS) MASTER RESET (MRS)
WRITE CLOCK (WCLK/WR)
READ CLOCK (RCLK/RD)
WRITE ENABLE (WEN)
READ ENABLE (REN)
OUTPUT ENABLE (OE)
WRITE CHIP SELECT (WCS)
LOAD (LD)
READ CHIP SELECT (RCS)
IDT
72T7285
72T7295
72T72105
72T72115
(x72, x36, x18) DATA IN (D
0
- D
n
)
(x72, x36, x18) DATA OUT (Q0 - Qn)
RCLK ECHO, ERCLK
REN ECHO, EREN
MARK
SERIAL CLOCK (SCLK)
SERIAL ENABLE(SEN)
FIRST WORD FALL THROUGH/
SERIAL INPUT (FWFT/SI)
RETRANSMIT (RT)
EMPTY FLAG/OUTPUT READY (EF/OR)
PROGRAMMABLE ALMOST-EMPTY (PAE)
HALF-FULL FLAG (HF)
FULL FLAG/INPUT READY (FF/IR)
PROGRAMMABLE ALMOST-FULL (PAF)
BIG-ENDIAN/LITTLE-ENDIAN (BE)
INTERSPERSED/
NON-INTERSPERSED PARITY (IP)
5994 drw03
OUTPUT WIDTH (OW)
INPUT WIDTH (IW)
BUS-
MATCHING
(BM)
Figure 1. Single Device Configuration Signal Flow Diagram
TABLE 1 — BUS-MATCHING CONFIGURATION MODES
BM
IW
OW
Write Port Width
Read Port Width
L
H
H
H
H
L
L
L
H
H
L
L
H
L
H
x72
x72
x72
x36
x18
x72
x36
x18
x72
x72
NOTE:
1. Pin status during Master Reset.
