iC-MH8
12 BIT ANGULAR HALL ENCODER
Rev A0.9, Page 8/25
OPERATING REQUIREMENTS: Serial Interface
Operating conditions: VPA, VPD = 5 V ±10 %, Ta = -40...125 °C, IBM calibrated to 200 µA;
Logic levels referenced to VND: lo = 0...0.45 V, hi = 2.4 V...VPD
Item Symbol
No.
Parameter
Conditions
Unit
Min.
Max.
SSI Protocol (ENSSI = 1)
I001 TMAS
I002 tMASh
I003 tMASl
Permissible Clock Period
tout determined by CFGTOS
250
25
2x tout
tout
ns
ns
ns
Clock Signal Hi Level Duration
Clock Signal Lo Level Duration
25
tout
Figure 1: I/O Interface timing with SSI protocol
